使用 .NET 代理 API 进行自定义检测

用于自定义检测的 .NET 代理 API

APM Insight .NET 代理 API 有助于跟踪 Web 应用程序中用户定义的方法。它有助于检测 Web 应用程序 DLL 中的指定方法以监控其性能。它还可用于跟踪代码的特定部分。

添加 API 的步骤

  1. 将对库 DotNetAgent.Api.dll的引用添加 到您的 Web 应用程序项目中。
  2. 该 dll 以NuGet 包的形式提供。
  3. API 包含一个名为CustomTracker的类，用于跟踪方法的性能。
  4. 还有ApiParameter类，其中包含要作为 CustomTracker 中的参数传递的方法名称、类名称和组件名称。

    CustomTracker 类及其方法

    Constructors

    CustomTracker(Type thisType)

    • thisType - The type of current class or base class.

              eg: CustomTracker dotNetAgentCustomTracker = new CustomTracker(this.GetType());

    CustomTracker(Type thisType, ApiParameters apiParameters)

    • thisType - The type of current class or base class.
    • apiParameters - Parameter values like class name, method name and component name for the monitoring method.

              eg: var customTracker = new CustomTracker(this.GetType(), new ApiParameters() { MethodName = "GetEmployeeReport", ComponentName = "REPORT" });

    Methods

    CustomTracker.StartTracker(Type thisType)

    • thisType - The type of current class or base class.
    • It is not required since it is called in constructor itself.

    CustomTracker.StartTracker (Type thisType, ApiParameters apiParameters)

    • This method is used to start the metric collection for the custom method.
    • It is not required as it is called in constructor itself.

    CustomTracker.StopTracker()

    • The metric collection will be stopped on calling this method.
    • Always call it in a finally block.

    CustomTracker.TraceError(System.Exception ex)

    • Tracking exception in web transactions.
    • It is a static method to be called on catch blocks.
  5. 在方法的开头创建 CustomTracker 类的实例，并在方法的结尾调用 StopTracker()。
  6. 我们可以使用 using{} 块创建 CustomTracker 实例。自动处理对象时会调用 StopTracker() 方法。

以下示例显示了此 CustomTracker 的用法：

示例 1：使用“using”语句：

protected void Page_Load(object sender, EventArgs e)
{
using (var customTracker = new CustomTracker(this.GetType(), new ApiParameters() { MethodName = "GetBasicDetails", ComponentName= "DETAILS" }))
 {
AdminBL adminBL = new AdminBL();
if(!IsPostBack)
     {
      ASPSite.BL.MYSQLReference.BasicDetails basicDetails = adminBL.getBasicDetails(id);
      EmpApp.Models.BasicDetails basicDetailsModel = getBasicDetailsModel(basicDetails);
     }
}
}

示例 2：在 try finally 块中使用 StartTracker 和 StopTracker：

public ActionResult BasicDetails(int id = 0)
{
    CustomTracker customTracker = null;
    AdminBL adminBL = new AdminBL();
    try
     {
        customTracker = new CustomTracker(base.GetType(),new ApiParameters(){ MethodName = "BasicDetails", ComponentName= "DETAILS" });
        ASPSite.BL.MYSQLReference.BasicDetails basicDetails = adminBL.getBasicDetails(id);
        EmpApp.Models.BasicDetails basicDetailsModel = getBasicDetailsModel(basicDetails);
     }
    finally
    {
    customTracker.StopTracker();
    }
return View(basicDetailsModel);
}

示例 3：使用 CustomTracker 检测代码的一部分。

public ActionResult BasicDetails(int id = 0)
{
            AdminBL adminBL = new AdminBL();
            using(CustomTracker customTracker = new CustomTracker(base.GetType(),new ApiParameters() { MethodName = "BasicDetails", ComponentName = "DETAILS" }))
             {
//Instrumenting part of a code. To check the time taken by the function FetchAllEmployees and the SQL calls made from this function.
using(CustomTracker fetchAllEmpTracker = new CustomTracker(base.GetType(),new ApiParameters() { MethodName = "FetchAllEmployees", ComponentName = "DETAILS_DB" }))
            {
     var empList = FetchAllEmployees();
            }
ASPSite.BL.MYSQLReference.BasicDetails basicDetails = objadmin.getBasicDetails(id);
EmpApp.Models.BasicDetails basic = getBasicDetailsModel(basicDetails);
}
return View(basicDetailsModel);
}

Example 4: Using TraceError to trace exceptions.

public ActionResult BasicDetails(int id = 0)
{
            try
            {
            AdminBL adminBL = new AdminBL();
     var empList = FetchAllEmployees();

ASPSite.BL.MYSQLReference.BasicDetails basicDetails = objadmin.getBasicDetails(id);

EmpApp.Models.BasicDetails basic = getBasicDetailsModel(basicDetails);
}
            catch (Exception ex)
            {
            //Exception will be traced for this transaction
 DotNetAgent.Api.CustomTracker.TraceError(ex);
            }

}

  1. 如果 CustomTracker 中没有给出方法名或类名，它将尝试自己获取当前的方法名和类名。
  2. 默认情况下将在构造函数中调用 StartTracker() 方法。
  3. 如果未安装代理或代理服务停止，则调用的方法将无效。
